Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine

Brand Name : SANROCK

Model Number : SR800S Customized

Certification : CE ISO 9001:2015

Place of Origin : Zhejiang, China

MOQ : 1Set/Sets per Month

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000Set/Sets per Month

Delivery Time : 15-30days

Packaging Details : Nude package for machines, Wooden box package for spare parts, Or customer demand.

Product name : Water Well Drilling Rig

Name : Water Well Drilling Rig Machine,Crawler Water Well Drilling Rig

Engine : diesel engine

Power type : Diesel

Power(w) : 176KW

Drilling depth : 750m

Drilling diameter : 105-450mm

Lifting force : 40T

Rotary Torque : 7500-15000Nm

Working pressure : 1.6-6Mpa

Air consumption : 16-75m3/min

Drill pipe diameter : 102mm / 89mm

Drill pipe length : 3.0m

Application : water well drilling rig mobile drilling rig,drilling well

Feature : High Drilling Efficiency,Hydraulic Controlling,Multifunctional

Usage : Water Well

Type : Rotary Drilling Rig

Dimension(l*w*h) : 6300*2250*2650mm

Weight : 14000 KG

Warranty : 12 months

Contact Now

Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling MachineWater Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine

The deep water well drilling rig demonstrates exceptional hydraulic efficiency during outdoor drilling operations, producing a robust water outflow with sustained high-yield performance. Equipped with a heavy-duty centrifugal pump system and optimized bit configuration, the rig achieves remarkable aquifer penetration rates.
Its adaptive pressure regulation system ensures maximum water recovery while maintaining drilling stability, making it particularly effective in high-permeability geological formations. The rig's enhanced fluid circulation design and 360° rotating drill head enable efficient sediment evacuation, contributing to both exceptional water volume output and extended equipment durability in demanding field applications.

Applications include agricultural irrigation systems, rural water supply projects, and industrial water extraction operations. Proper slurry circulation management ensures aquifer penetration while preventing borehole collapse. When properly sited using hydrogeological surveys, making them ideal solutions for semi-arid regions and large-scale water supply initiatives.

Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine

Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling MachineWater Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine
Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine
Feature:
This machine can drill in different stratum, The maximum bore diameter can be 800mm.
This machine adopts big torque hydraulic motor for power head and brand diesel, big diameter hydraulic cylinders for the hydraulic control system.
Unique bump set design and centralize controlled operation system is easy to maintain and convenient for machine operation.
This machine adopts excavator crawler chassis and make the machine a high off-road performance.
Water Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling MachineWater Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling MachineWater Well Drilling Rig Crawler Drilling Rig Underground Water Well Drilling Machine
Products Description
Product name
Water Well Drilling Rig
Model
Unit
SR800S
Max drilling depth
M
750
Drilling diameter
mm
105-450
Engine brand
/
Weichai
Power
kw
176
Rotary motor brand
/
Danfoss
Pump brand
/
/
Air pressure
Mpa
1.6-6
Air consumption
m³/min
16-75
Drill pipe length
m
6
Drill pipe diameter
mm
102
Axial pressure
T
6
Lifting force
T
40
Fast lifting speed
m/min
31
Fast feeding speed
m/min
65
Max rotary torque
Nm
12600/6300
or15000/7500
Max rotary speed
r/min
95/190
Big auxiliary winch lifting force
T
/
Small auxiliary winch lifting force
T
2.5
Jacks stroke
m
1.6
Drilling efficiency
m/h
10-35
Moving speed
Km/h
3
Uphill angle
/
21°
Weight
T
14
Dimension
mm
6300*2250*2650
